Fume Hood Complete Test Set according to ASHRAE 110-2016 (Hardware and Software)

SKU: Complete FH ASHRAE 110 Performance Testing Setup

Complete Fume Hood Testing Kits for ASHRAE 110-2016

Fume hood performance testing requires a lot of hardware and professional software.The fume hood performance testing kit manufactured by D-Industrial contains everything (hardware and software) required to perform ANSI/ASHRAE 110-2016 ( as manufactured- AM, as installed- AI and as used- AU). D-Industrial fume hood performance test kit was designed on the basis of more than 5 years of fume hood testing experience. It has a powerful fume hood test hardware and software configuration and is fully mobile even in complex field environments.

Features :

ANSI/ASHRAE 110 is the international standard for chemical fume hood performance testing
D-Industrial’s fume hood performance test kits is widely use for the testing of fume hoods in accordance to ANSI/ASHRAE 110-2016 standards;
The SF6 ejector was manufactured according to standard drawing # 110-83m;
The internal critical orifice is accurately calibrated by the mass flow meter to ensure the flow rate of 4 L/min
The SF6 Tracer Gas Analyzer Q200 and Mannequin are provided for Tracer Gas Test
The high accuracy Face Velocity Test Kit measures multiple air face velocity at sash opening of fume hood. Test data can be recorded, calculated and exported in real time by professional software;
D-Industrial fume hood performance test software guides each step of fume hood performance test, automatically records all original data of fume hood performance test, and finally automatically generates a complete test report. All this made possible with ASHRAE compliance performance test Software.

The complete system consist of following equipment as a total solution :

SF6 Tracer Gas Analyzer Q200

The SF6 tracer gas analyzer Q200 uses advanced ECD sensing technology and can detect at least 0.01ppm SF6.The Q200 response time (T90) is less than 1 second, and the reading can be stabilised at the maximum concentration in less than 2 seconds.
Description : Ultra High Sensitivity SF6 Trace Gas Leak Detector
– Sensor : Electron capture
– Leak Rate : 1 x 10-8 ml/s , 0.1ppm [With optional capillary inlet,1 x 10-10mL/s SF6]
– Response : 1 sec (85% of reading)
– Concentration Sensitivity : 0.01 ppm
– Recovery time : ＜2sec
– Accuracy : ±5% of reading
– Dimensions(h x w x d) : Case: 43 x 40 x 23 cm
– Weight : Hand held probe: 0.9 Kg (2.0 lbs)
– Output : RS232 interface port Analogue 0–2 V
– Battery use time : 20 Hours
– Display : Alpha numeric VFD
– Options : Calibrated leaks
– Manufacturing Standards : To ISO 9001:2015 Certified to CE requirements

2. SF6 Ejector Kit

The SF6 Ejector kit includes: SF6 ejector, calibrated critical orifice (release flow 4 L/min at 30 psi), special gas pressure regulator, pressure gauge (0 to 60 psi), and quick connector.
The SF6 ejector is manufactured according to the ANSI/ASHRAE 110-2016-4.2 Ejector System (FIGURE 4.1 to 4.3).The Orifice was manufactured in accordance with the ANSI/ASHRAE 110-2016-4.3 Orifice parameters, and the release rate of SF6 was controlled to be 4 liters per minute (4 Lpm) at the pressure of 30 psi.
Specifications
– SF6 Ejector : manufactured according to ANSI/ASHRAE 110-2016-4.2 Ejector System（FIGURE 4.1to 4.3）
– Orifice : At 30 psi, SF6 releases at a rate of 4 l/min(4 Lpm)
– Gas pressure Regular : Double pressure gauges, suitable for special gases
– Pressure Gauge : 0 to 60 psi

3. Face Velocity Test kit with data logging

Four high precision air velocity transducer and high performance data logger are integrated.Through it, the face velocity of the fume hood can be tested quickly without interference, and the data can be automatically recorded, calculated and reported by special software.
Face Velocity Kit Specification
– Air Velocity Transducer : Range：0.15 – 2 m/sReading accuracy ±3%or（±0.15 m/s）
– Data Logger : The full range accuracy is 0.092%, and the acquisition frequency can reach 50000 times/channel/second
– Weight : 6 kg
– Power : Use built-in lithium battery or alternating current

4. Small Portable Smoke Generator

The Smoke Generator is mainly used for visualiaation test of fume hood .It includes a small smoke generator and a large smoke generator.
Because testers often face the fume hood when performing tests, extra care should be taken to ensure that the tester’s body does not interfere with smoke visualisation.
Safe, non – toxic, non – flammable pharmaceutical – grade smoke oil, specially designed for this smoke machine, can provide high quality safety smoke generation.The rapid diffusion of smoke produced by the smoky oil makes the device suitable for various applications, such as visualiaation of laboratory airflow patterns. A 500mL smoky oil can provide a total of 250 minutes (over 4 hours) of smoke generation at high smoke production (2mL/min consumption) and 500 minutes (8 hours) of smoke generation at low smoke production (1mL/min consumption).

5. Large Volume Smoke Generator

Equipped with 1000W high-power smoke generator and electronic thermostatic control system, it can continuously generate a large amount of white smoke

6. Manniquin Stand

The mannequin kit includes a mannequin, a retractable support frame and a lab coat. The mannequin is compatible with the parameter requirements specified in ANSI/ASHRAE 110-2016.

Software for ASHRAE 110-2016

Compatible with ANSI/ASHRAE 110-2016 Fume Hood Performance Test Program

D-Industrial specially designed the fume hood testing program for ASHRAE 110-2016 standard. By connecting D-Industrial fume hood test hardware, this program can guide user step by step to complete all the test items in ASHRAE 110-2016, and finally automatically generate and print test reports. The test program includes Test Conditions, and Fume Hood Information Record, Cross Draft Test, Face Velocity Test, VAV Face Velocity Control Test, VAV Response and Steady Time, Flow Visualization Test, SF6 Tracer Gas Tests.

Technical Specification:

Record the test conditions and information of the fume hood, including model, size, test conditions, equipment and instruments, etc.

SF6 Tracer Gas Tests, Including Tracer Gas Tests, Peripheral Scan Test and Sash Movement Containment Test. Record data in real time, generate time-concentration graphs, and automatically calculate.

Cross Draft Test, Real-time data reading, recording and calculation.

Face Velocity and VAV Face Velocity Control Test, Real-time data reading, recording and calculation.

VAV Response and Steady Test, Real-time data reading, recording, generate Time-Signal graphs and calculation. Time recording and calculation can be accurate to 0.1 second.
