WATER BATH
Order No |
Model No |
Outer dimensions(mm) |
Effective internal dimensions(mm) |
1-4594-82 |
TMK-2K |
190x336x156 |
147x150x307 |
Specifications
- Type: Water bath
- Operating temperature range: Room temperature +5 – 80℃
- Temperature settings range: -20.0 to +80.0℃ (*Use the external cooling unit (optional) for temperature control below the room temperature. )
- Chamber capacity: 190 x 336 x 156mm
- Jet stirring method
- Function: Program (maximum 8 steps), Float type no-water burning prevention, buzzer alarm, Abnormal heating prevention device (thermostat)
- Configuration: Sensor/K thermocouple sensor, Heater capacity/1kW
- Pump capacity: Maximum discharge quantity 10L/min, Maximum pump head 1.4m
- Timer setting range: 1 minute – 99 hours 59 minutes (1 minute unit)
- Clamp attachable width: 40mm
- Power supply: 220V±10％
- Accessories: Water tank (heat resistant ABS resin)
- External dimensions: 147 x 150 x 307mm
- Control Panel: English
- Plug: Type F(https://en.wikipedia.org/wiki/Mains_electricity_by_country)
- RoHS3 (EU)2015/863 Certificates can be issued [About RoHS]
